API 5CT Casing Pipe with Coupling & Thread Protector

Basic Info.

Model NO.	20′′,18-5/8′′,16′′,13-3/8′′,9-5/8′′,7′′,5-1/2′′
Certification	API, ISO
Temperature Classification	High Temperature Piping
MPa Classfication	High Pressure Piping
Material	Carbon Steel
Standard	API
Diameter	720mm
Medium	Gas
Cross-Section Shape	Round
Connection Type	Thread
Transport Package	Bundle / Loose
Specification	20′′,18-5/8′′,16′′,13-3/8′′,9-5/8′′,7′′,5-1/2′′
Trademark	TTSP
Origin	Tianjin China
HS Code	73042900
Production Capacity	200000 Tons/Year

Product Description

Seamless casing pipe with coupling and thread protector
Standard: API 5ct (certificate no. 5ct 023)
Outside diameter: 4-1/2''--------20''
Steel grade: H40, J55, K55, N80, L80, P110, C90, C95, T95, Q125
Thread type: LTC, STC, BTC, PREMIUM CONNECTION
Length range: R1, R2, R3
Mainly product: Seamless casing, seamless tubing, seamless oil pipe, natural gas pipe, seamless steel pipe etc.

WE ALSO OFFER NEW VAM, VAM TOP AND SO ON PREMIUM CONNECTION

TUBING PIPES
STANDARD: API SPEC 5CT
Outside Diameter Specified(mm)	Nominal Weight Threads & Coupling	Steel Grade	Wall Thickness (mm)	Type of Thread
	Ib/ft			N U		E U
60.32(2 3/8" )	4.70	H40/J55/K55/N80/L80/P110	4.83	YES		YES
	5.80	H40/J55/K55/N80/L80/P110	6.45	YES		YES
	5.95	H40/J55/K55/N80/L80/P110	6.45	YES		YES
	7.35	H40/J55/K55/N80/L80/P110	8.53			YES
	7.45	H40/J55/K55/N80/L80/P110	8.53			YES
73.02(2 7/8" )	6.40	H40/J55/K55/N80/L80/P110	5.51	YES
	6.50	H40/J55/K55/N80/L80/P110	5.51			YES
	7.80	H40/J55/K55/N80/L80/P110	7.01	YES
	7.90	H40/J55/K55/N80/L80/P110	7.01			YES
	8.60	H40/J55/K55/N80/L80/P110	7.82	YES
	8.70	H40/J55/K55/N80/L80/P110	7.82			YES
	9.45	H40/J55/K55/N80/L80/P110	8.64			YES
88.90(3 1/2" )	9.20	H40/J55/K55/N80/L80/P110	6.45	YES
	9.30	H40/J55/K55/N80/L80/P110	6.45			YES
	10.20	H40/J55/K55/N80/L80/P110	7.34	YES
	12.70	H40/J55/K55/N80/L80/P110	9.52	YES		YES
	12.95	H40/J55/K55/N80/L80/P110	9.52			YES
101.60(4" )	9.50	H40/J55/K55/N80/L80/P110	5.74	YES
	11.00	H40/J55/K55/N80/L80/P110	6.65			YES
114.30(4 1/2" )	12.60	H40/J55/K55/N80/L80/P110	12.75	YES
	12.75	H40/J55/K55/N80/L80/P110	12.75			YES
CONTACT:	Mr MARKMA
CASING PIPES
STANDARD: API SPEC 5CT
Outside Diameter Specified(mm)	Nominal Weight Threads & Coupling	Steel Grade	Wall Thickness (mm)	Type of Thread
	Ib/ft			Short	Long	Buttress	TG-QMI
114.30(4 1/2" )	9.50	H40/J55/K55/N80/L80/P110	5.21	YES
	10.50	H40/J55/K55/N80/L80/P110	5.69	YES		YES
	11.60	H40/J55/K55/N80/L80/P110	6.35	YES	YES	YES
	13.50	H40/J55/K55/N80/L80/P110	7.37		YES	YES
	15.10	H40/J55/K55/N80/L80/P110	8.56		YES	YES
127.00(5" )	11.50	H40/J55/K55/N80/L80/P110	5.59	YES
	13.00	H40/J55/K55/N80/L80/P110	6.43	YES	YES	YES
	15.00	H40/J55/K55/N80/L80/P110	7.52	YES	YES	YES
	18.00	H40/J55/K55/N80/L80/P110	9.19		YES	YES
	21.40	H40/J55/K55/N80/L80/P110	11.10		YES	YES
	23.20	H40/J55/K55/N80/L80/P110	12.14		YES	YES
	24.10	H40/J55/K55/N80/L80/P110	12.70		YES	YES
139.70(5 1/2" )	14.00	H40/J55/K55/N80/L80/P110	6.20	YES
	15.50	H40/J55/K55/N80/L80/P110	6.98	YES	YES	YES	YES
	17.00	H40/J55/K55/N80/L80/P110	7.72	YES	YES	YES	YES
	20.00	H40/J55/K55/N80/L80/P110	9.17		YES	YES	YES
	23.00	H40/J55/K55/N80/L80/P110	10.54		YES	YES	YES
168.28(6 5/8" )	20.00	H40/J55/K55/N80/L80/P110	7.32	YES	YES	YES
	24.00	H40/J55/K55/N80/L80/P110	8.94	YES	YES	YES
	28.00	H40/J55/K55/N80/L80/P110	10.59		YES	YES
	32.00	H40/J55/K55/N80/L80/P110	12.06		YES	YES
177.80(7" )	20.00	H40/J55/K55/N80/L80/P110	6.91	YES
	23.00	H40/J55/K55/N80/L80/P110	8.05	YES	YES	YES	YES
	26.00	H40/J55/K55/N80/L80/P110	9.19	YES	YES	YES	YES
	29.00	H40/J55/K55/N80/L80/P110	10.36		YES	YES	YES
	32.00	H40/J55/K55/N80/L80/P110	11.51		YES	YES	YES
	35.00	H40/J55/K55/N80/L80/P110	12.65		YES	YES	YES
	38.00	H40/J55/K55/N80/L80/P110	13.72		YES	YES	YES
193.68(7 5/8" )	24.00	H40/J55/K55/N80/L80/P110	7.62	YES
	26.40	H40/J55/K55/N80/L80/P110	8.33	YES	YES	YES
	29.70	H40/J55/K55/N80/L80/P110	9.52		YES	YES
	33.70	H40/J55/K55/N80/L80/P110	10.92		YES	YES
	39.00	H40/J55/K55/N80/L80/P110	12.70		YES	YES
	42.80	H40/J55/K55/N80/L80/P110	14.27		YES	YES
	45.30	H40/J55/K55/N80/L80/P110	15.11		YES	YES
	47.10	H40/J55/K55/N80/L80/P110	15.88		YES	YES
196.85(7 3/4" )	46.10	H40/J55/K55/N80/L80/P110	15.11
219.08(8 5/8" )	24.00	H40/J55/K55/N80/L80/P110	6.71	YES
	28.00	H40/J55/K55/N80/L80/P110	7.72	YES
	32.00	H40/J55/K55/N80/L80/P110	8.94	YES	YES	YES
	36.00	H40/J55/K55/N80/L80/P110	10.16	YES	YES	YES
	40.00	H40/J55/K55/N80/L80/P110	11.43		YES	YES
	44.00	H40/J55/K55/N80/L80/P110	12.70		YES	YES
	49.00	H40/J55/K55/N80/L80/P110	14.15		YES	YES
244.48(9 5/8" )	32.30	H40/J55/K55/N80/L80/P110	7.92	YES
	36.00	H40/J55/K55/N80/L80/P110	8.94	YES	YES	YES	YES
	40.00	H40/J55/K55/N80/L80/P110	10.03		YES	YES	YES
	43.50	H40/J55/K55/N80/L80/P110	11.05		YES	YES	YES
	47.00	H40/J55/K55/N80/L80/P110	11.99		YES	YES	YES
	53.50	H40/J55/K55/N80/L80/P110	13.84		YES	YES	YES
273.05(10 3/4" )	32.75	H40/J55/K55/N80/L80/P110	7.09	YES
	40.50	H40/J55/K55/N80/L80/P110	8.89	YES		YES
	45.50	H40/J55/K55/N80/L80/P110	10.16	YES		YES
	51.00	H40/J55/K55/N80/L80/P110	11.43	YES		YES
	55.50	H40/J55/K55/N80/L80/P110	12.57	YES		YES
	60.70	H40/J55/K55/N80/L80/P110	13.84	YES		YES
	65.70	H40/J55/K55/N80/L80/P110	15.11	YES		YES
298.45(11 3/4" )	42.00	H40/J55/K55/N80/L80/P110	8.46	YES
	47.00	H40/J55/K55/N80/L80/P110	9.53	YES		YES
	54.00	H40/J55/K55/N80/L80/P110	11.05	YES		YES
	60.00	H40/J55/K55/N80/L80/P110	12.42	YES		YES
339.7(13 3/8" )	48.00	H40/J55/K55/N80/L80/P110	8.38	YES
	54.50	H40/J55/K55/N80/L80/P110	9.65	YES		YES
	61.00	H40/J55/K55/N80/L80/P110	10.92	YES		YES
	68.00	H40/J55/K55/N80/L80/P110	12.19	YES		YES
	72.00	H40/J55/K55/N80/L80/P110	13.06	YES		YES
406.40(16" )	65.00	H40/J55/K55	9.53	YES
	75.00	H40/J55/K55	11.13	YES		YES
	84.00	H40/J55/K55	12.57	YES		YES
473.08(1.5/8" )	87.50	H40/J55/K55	11.05	YES	YES	YES
508.00(20" )	94.00	H40/J55/K55	11.13	YES	YES	YES
	106.50	H40/J55/K55	12.70	YES	YES	YES
	133.00	H40/J55/K55	16.13	YES	YES	YES
